SPL 1400LC / SPL 1400CG
SEIGER face lathe: The miracle of compact design for the economic production of large diameters with a small part length
![SEIGER SPL 1400LC / SPL 1400CG Drehmschine](/files/0352_header_bild_1.png)
SPL 1400LC / SPL 1400CG
SEIGER face lathe: The miracle of compact design for the economic production of large diameters with a small part length
Information
General information
Face lathe SPL 1400LC
- Available with CNC or cycle control from Siemens or Heidenhain
- Different travel paths in the axes and different spindle boxes
- Adjustable support for different part lengths
- Different paneling variants as partial or full paneling
- CNC control Heidenhain MANUALplus 620/640 or Siemens 840D Solution Line Operate with manual functions
Face lathe SPL 1400CG
- Available with CNC or cycle control
- Different travel paths in the two axes and different spindle boxes
- Different paneling variants as partial or full paneling
- CNC control Heidenhain MANUALplus 620/640 or Siemens 840D Solution Line Operate with manual functions
Overview of features
Photos
Specifications and performance
Specifications
Unit | SPL 1400CG | SPL 1400LC | |
---|---|---|---|
Swing in the bridge | mm | 1.400 – 2.300 | 1.400 – 2.300 |
Swing over the lathe cheek guides | mm | – | 1.000 – 1.900 |
Bridge opening | mm | 300 – 900 | 300 – 1.500 |
Spindle head in accordance with DIN 55027 | Size | 15 – 28 (Option) | 15 – 28 (Option) |
Spindle bore Ø | mm | 130 – 530 (Option) | 130 – 530 (Option) |
Travel path of the positioning support | mm | – | 400 – 800 |
Operating travel cross slide | mm | 400 – 1.200 | 400 – 1.200 |
Operating travel saddle | mm | 300 – 800 | 300 – 800 |
Performance
Unit | SPL 1400CG | SPL 1400LC | |
---|---|---|---|
Main drive | KW | 30 – 46 | 46 – 70 |
Speed range | 1/min | 1 – 1.200 | 1 – 700 |
Dimensions | |||
Length | mm | 4.050 | 5.500 |
Width | mm | 3.880 | 4.050 |
Height | mm | 2.300 | 2.500 |
