SLZ 300E
SEIGER cycle lathe: The smallest lathe for big tasks from Seiger
Information
General information
- Available with CNC or cycle control from Siemens or Heidenhain
- Safety clutch in the Z-axis
- Torsion-resistant bed made of high-quality cast iron with hardened precisely ground slideways and glass scale on the X-axis
- The control panel can be moved and pivoted freely
- High degree of precision and rigidity of spindles thanks to precise spindle bearing, spindle bore Ø 40 mm as standard, Ø up to 55 mm as an option
Overview of features
Photos
Specifications and performance
Specifications
SLZ 300E | Unit | Value |
---|---|---|
Swing over bed | mm | 300 |
Swing over cross slide | mm | 150 |
Bed width | mm | 240 |
Spindle head in accordance with DIN 55027 | Size | 5 |
Spindle bore Ø | mm | 40 / 55 (Option) |
Spindle Ø in the front bearing | mm | 70 / 90 (Option) |
Tailstock quill Ø | mm | 50 |
Tailstock stroke | mm | 125 |
Tailstock Morse taper | MK | 3 |
Center distance | mm | 750 |
Performance
SLZ 300E | Unit | Value |
---|---|---|
Main drive | KW | 11,5 |
Speed range | 1/min | 1 – 4.500 |
Dimensions | ||
Length | mm | 2.000 |
Width | mm | 1.800 |
Height | mm | 1.850 |
